Physics Oscillations

Given below are two statements:

Statement I : A second's pendulum has a time period of 1 second.

Statement II : It takes precisely one second to move between the two extreme positions.

In the light of the above statements, choose the correct answer from the options given below:

0 Follower 1 View

Contributor-Level 10

Kindly go through the solution

Time period of second pendulum is 2 seconds.

0 0

New answer posted

3 months ago

A particle executes S.H.M., the graph of velocity as a function of displacement is:

0 Follower 2 Views

Contributor-Level 10

Kindly go through the solution

-> $v = ω \sqrt[]{A^{2} - x^{2}} \Rightarrow \frac{v^{2}}{A^{2} ω^{2}} + \frac{x^{2}}{A^{2}} = 1$ Path is ellipse.

0 0

New answer posted

3 months ago

The potential energy (U) of a diatomic molecule is a function dependent on r (interatomic distance) as $U = \frac{α}{r^{10}} - \frac{β}{r^{5}} - 3$

Where, α and β are positive constants. The equilibrium between two atoms will be ${(\frac{2 α}{β})}^{\frac{a}{b}},$ where α =…………….

0 Follower 2 Views

Contributor-Level 10

For equilibrium,

$\frac{d U}{d r} = 0 \Rightarrow \frac{- 10 α}{r^{11}} + \frac{5 β}{r^{6}} = 0 \Rightarrow r = {(\frac{2 α}{β})}^{\frac{1}{5}}$

0 0

New answer posted

3 months ago

A student is performing the experiment of resonance column. The diameter of the column tube is 6cm. THE Frequency of the tuning fork is 504 Hz. Speed of the sound at the given temperature is 336m/s. The zero of the meter scale coincides with tip end of the resonance column tube. The reading of the water level in the column when the first resonance occurs is:

0 Follower 2 Views

Physics Oscillations Oscillations

Contributor-Level 10

For first resonance,

$l + 0.3 d = \frac{v}{4 f}$

$\Rightarrow l + 0.3 * 6 = \frac{336 * 100}{4 * 504} \Rightarrow l = 14.8 c m$

0 0

New answer posted

3 months ago

If the time period of a two meter long simple pendulum is 2s, the acceleration due to gravity at the place where pendulum is executing S.H.M. is:

0 Follower 2 Views

Physics Oscillations Oscillations

Contributor-Level 10

$T = 2 π \sqrt[]{\frac{l}{g}}$

$\Rightarrow 2 = 2 π \sqrt[]{\frac{2}{g}}$

$\Rightarrow g = 2 π^{2} m / s^{2}$

0 0

New answer posted

3 months ago

In the given figure, a mass M is attached to a horizontal spring which is fixed on one side to a rigid support. The spring constant of the spring is k. The mass oscillates on a frictionless surface with time period T and amplitude A. When the mass is in equilibrium position, as shown in the figure, another mass m is gently fixed upon it. New amplitude of oscillation will be:

0 Follower 3 Views

Contributor-Level 10

Velocity of block in equilibrium, in first case,

$v = A ω = A . \sqrt[]{\frac{k}{M}}$

Velocity of block in equilibrium, is second case,

$v' = A' ω' = A' \sqrt[]{\frac{k}{M + m}}$

From conservation of momentum,

Mv = (M + m) v'

$\Rightarrow M A \sqrt[]{\frac{k}{M}} = (M + m) A' \sqrt[]{\frac{k}{M + m}} \Rightarrow A' = A \sqrt[]{\frac{M}{M + m}}$

0 0

New answer posted

3 months ago

The motion of a simple pendulum executing S.H.M. is represented by the following equation. $y = A s i n (π t + ?),$ where time is measured in second.

The length of pendulum is

0 Follower 2 Views

Contributor-Level 10

According to question, we can write

$ω = π = \sqrt[]{\frac{g}{l}} \Rightarrow l = \frac{g}{π^{2}} = \frac{9.8}{{(3.14)}^{2}} = 0.99395 = 99.4 c m$

0 0

New answer posted

3 months ago

Time period of a simple pendulum in a stationary lift is 'T'. If the lift accelerated with $\frac{g}{6}$ vertically upwards then the time period will be:

(Where g = acceleration due to gravity)

0 Follower 2 Views

Raj Pandey

Contributor-Level 9

$g_{e f f} = g + a$

$= g + \frac{g}{6}$

$= \frac{7 g}{6}$

$T' = 2 π \sqrt[]{\frac{l}{g_{e f f}}}$

$T' = \sqrt[]{\frac{6}{7}} T$

0 0

New answer posted

3 months ago

In an experiment to determine the velocity of sound in air at room temperature using a resonance tube, the first resonance is observed when the air column has a length of 20.0 cm for a tuning form of frequency 400 Hz is used. The velocity of the sound at room temperature is 336 ms^-¹. The third resonance is observed when the air column has a length of ____________cm.

0 Follower 2 Views

Contributor-Level 10

According to Concept of resonance tube, we can write

$\frac{λ}{4} + e = l_{1} a n d \frac{3 λ}{4} + e = l_{2} \Rightarrow \frac{λ}{2} = l_{2} - l_{1} \Rightarrow \frac{V}{2 ν} = l_{2} - l_{1}$

$\Rightarrow l_{2} = \frac{v}{2 ν} + l_{1} = \frac{336}{400} + 0.20 = 0.84 + 0.20 = 1.04 m = 104 c m$

0 0

New answer posted

3 months ago

The motion of a simple pendulum executing S.H.M. is represented by the following equation. $y = A s i n (π t + ϕ),$ where time is measured in second.

The length of pendulum is

0 Follower 3 Views
