JEE Main electrostatics questions typically test Coulomb's law, Gauss's law, electric field/potential due to standard geometries, dipoles, and capacitors. The questions are generally based on formula application, ratios, and calculus-based field-potential relationships. Check below electrostatics questions for JEE Main 2027.
JEE Main Electrostatics Questions 2027
JEE Main Electrostatics Questions 2027: In the JEE Main exam, Electrostatics (comprising Electric Charges & Fields, Electrostatic Potential, and Capacitance) consistently accounts for 6.5% to 8.5% of the total Physics section, averaging 2 to 3 questions per shift (8 to 12 marks). It is one of the most important chapters from JEE Mains syllabus for Physics.
The JEE Mains 2027 exam aspirants must focus on this chapter to score well. Based on past year trends, the majority of questions are numerical-heavy. Get JEE Main important questions from electrostatics to prepare for the upcoming exam cycle here.
- Key Highlights for JEE Main Electrostatics
- JEE Mains 2027 Electrostatics Questions
- JEE Main Electrostatics Weightage: 5-Year Trend Analysis (2021 to 2026)
- JEE Mains Electrostatics Concept-Wise Weightage (2021 to 2026)
- Preparation Strategy for Electrostatics Chapters for JEE Main 2027
Key Highlights for JEE Main Electrostatics
Shiksha experts have carefully analysed the past 5 year JEE Main question papers. The following observation has been made for the Electrostatics questions asked in the exam:
- Consistent appearance each year: 2 to 3 questions per shift
- Most repeated concept: Capacitors with Dielectrics, Electric Potential & Potential Energy, Gauss’s Law & Flux, Coulomb’s Law & Electric Fields
- Lengthy vs Tricky: Electrostatics questions generally strike a balance between being tricky (conceptual) and lengthy (calculation-heavy).
JEE Mains 2027 Electrostatics Questions
Below, candidates can download the JEE Main questions for the Electrostatics chapter. These questions have been curated from the past 5 year JEE Mains question papers.
Question 1
Two identical conducting spheres A and B, having charges +q and −q respectively, are placed at a distance d apart. The force between them is F. A third uncharged identical sphere C is brought in contact with sphere A, then with sphere B, and finally removed. The new electrostatic force between A and B is:
(A) F/8
(B) 3F/8
(C) F/4
(D) 3F/4
Answer: (A)
Question 2
An electric dipole of moment p = (2î + 3ĵ) × 10−29 C·m is placed in an electric field E = 4î × 104 N/C. The magnitude of torque acting on the dipole is:
(A) 1.2 × 10−24 N·m
(B) 8.0 × 10−24 N·m
(C) 2.4 × 10−24 N·m
(D) zero
Answer: (A)
Question 3
The electric potential at a point (x, y, z) is given by V(x, y, z) = −x2y − xz3 + 4. The electric field E at that point is:
(A) (2xy + z3)î + x2ĵ + 3xz2k̂
(B) 2xyî + (x2 + y)ĵ + 3xz2k̂
(C) (2xy − z3)î + x2ĵ − 3xz2k̂
(D) (2xy + z3)î − x2ĵ − 3xz2k̂
Answer: (A)
Question 4
A spherical solid insulator of radius R contains a uniform volume charge density ρ. The ratio of the electric field magnitude at a distance r1 = R/2 to that at r2 = 2R from the center is:
(A) 1 : 2
(B) 2 : 1
(C) 1 : 1
(D) 4 : 1
Answer: (B)
Question 5
A parallel plate capacitor with initial capacitance C0 is charged to potential V0 and then disconnected from the battery. A dielectric slab of dielectric constant K = 4 is inserted between the plates. If U0 is the initial stored energy, the new stored energy U is:
(A) 4U0
(B) 16U0
(C) U0/4
(D) U0
Answer: (C)
Question 6
An electric dipole of moment p is placed at the origin along the z-axis. The ratio of the magnitude of electric field at point A(0, 0, d) to that at point B(d, 0, 0) is (for d >> dipole length):
(A) 1 : 1
(B) 2 : 1
(C) 1 : 2
(D) 4 : 1
Answer: (B)
Question 7
64 identical mercury droplets, each charged to a potential of 10 V, coalesce into a single larger drop. The potential of the combined drop is:
(A) 40 V
(B) 160 V
(C) 640 V
(D) 20 V
Answer: (B)
Question 8
A point charge q = 8.85 × 10−12 C is placed at the center of a cubical Gaussian surface of side a = 10 cm. The electric flux passing through one face of the cube is:
(A) 1.000 N·m2/C
(B) 0.167 N·m2/C
(C) 6.000 N·m2/C
(D) 0.333 N·m2/C
Answer: (B)
Question 9
Two point charges +4q and +q are fixed at a distance L apart. A third charge Q is placed on the line segment joining them such that the system is in equilibrium. The position and value of Q are:
(A) at distance 2L/3 from +4q, with Q = −(4/9)q
(B) at distance L/3 from +4q, with Q = −(4/9)q
(C) at distance 2L/3 from +4q, with Q = +(4/9)q
(D) at distance L/2 from +4q, with Q = −q
Answer: (A)
Question 10
A thin semi-circular ring of radius R carries a uniform linear charge density +λ on one half and −λ on the other half. The magnitude of the electric field at the center of curvature is:
(A) λ / (2πε0R)
(B) √2λ / (πε0R)
(C) λ / (πε0R)
(D) λ / (4πε0R)
Answer: (C)
JEE Main Electrostatics Weightage: 5-Year Trend Analysis (2021 to 2026)
Check below the overall weightage of Electrostatics in JEE Mains exam from 2026 to 2021:
| Exam Year |
Average Questions per Shift |
Weightage in Physics Section |
Difficulty Trend |
|---|---|---|---|
| JEE Main 2026 |
2 - 3 |
7.5% - 8.0% |
Moderate, formula & circuit-heavy |
| JEE Main 2025 |
2 - 3 |
7.0% - 7.8% |
Moderate with multi-concept integration |
| JEE Main 2024 |
2 - 3 |
7.5% - 8.3% |
Formula-based, high calculation load |
| JEE Main 2023 |
2 - 3 |
6.8% - 7.5% |
Moderate, focus on Gauss's Law & Potentials |
| JEE Main 2022 |
2 - 3 |
7.3% - 8.0% |
Direct applications & symmetry problems |
| JEE Main 2021 |
2 - 3 |
8.0% - 8.7% |
Higher frequency due to 30-question format |
JEE Mains Electrostatics Concept-Wise Weightage (2021 to 2026)
The Electrostatics chapters contain subtopics or concepts. Not all subtopics carry equal weightage - some carry more weightage (frequency/yield). We have analysed which topics and concepts from Electrostatics have been asked most frequently in the past 5 years in the JEE Main exam. Check below:
| Subtopic / Unit |
Share of Questions |
Key Concepts & High-Yield Focus Areas |
|---|---|---|
| Capacitance & Dielectrics |
40% |
Combinations of capacitors (series/parallel, infinite ladders) Dielectric insertion (with/without battery connected) Common potential and energy loss during charge redistribution Force between capacitor plates |
| Electric Potential & Potential Energy |
25% |
Relation between electric field and potential Work done moving charges in conservative field Potential due to concentric conducting/non-conducting spheres Dipole potential and interaction energy |
| Gauss’s Law & Flux |
20% |
Flux through regular surfaces (cubes, cylinders, open cones) Field calculation for spherical, cylindrical, and planar symmetries Cavity problems in charged non-conducting spheres |
| Coulomb’s Law & Electric Fields |
15% |
Equilibrium of point charge systems (stable vs. unstable) Superposition principle with vector geometry Motion of charged particles in uniform electric fields Torque and dipole oscillations in external fields |
Commonly asked questions
Best free mock tests for JEE Mains are previous year question papers. You can also practice NTA mock tests online at nta.ac.in. All mock tests are designed as per JEE Main syllabus and exam pattern.
Usually, in the JEE Mains computer-based exam, questions from maths are presented first, followed by Physics and Chemistry.
But candidates can appear for any section first, as per their preference.
Yes, JEE Main exam has negative marking. 1 mark is deducted for every incorrect answer.
Candidates should take JEE Main mock tests at least once a week. However, in the last month before exam, frequency should be increased to 3 to 4 mock exam per week.
Preparation Strategy for Electrostatics Chapters for JEE Main 2027
Based on the recent trends in Electrostatics questions asked in NTA JEE Mains exam, here are some strategies that candidates should focus on while preparing for this important chapter from the JEE Mains 2027 syllabus:
- Master Class 11 Concepts: Ensure strong command over Vectors (component resolution, dot/cross products), Work-Energy Theorem, and basic Calculus (integration for continuous charge distributions) before going deep, as these mechanics principles directly govern electric field and potential problems.
- Categorise by Core Sub-Units: Divide the topic into four structured pillars:
- Forces & Fields (Coulomb's Law, Superposition principle)
- Gauss’s Law & Flux (Standard symmetries: spherical shells, solid spheres, infinite planes/cylinders)
- Electrostatic Potential & Energy
- Capacitors & Dielectrics (Series/parallel combinations, energy density, dielectric insertions).
- Practice Standard Derivations & Graph Sketching: Practice drawing graphs for conducting and non-conducting geometries (like hollow vs. solid spheres). JEE Main consistently tests graphical interpretation and field variations.
- Solve 2021 to 2026 JEE Main PYQs: Solve at least 150 to 200 previous year questions from this chapter. Group them topic-wise to identify recurring numerical patterns, especially dielectric slab insertions and charge redistribution among connected conductors.
Commonly asked questions
Yes, and in fact, in the JEE Main exam, the weightage of class 11 and topics is almost the same. Candidates have to study topics of both classes 11 and 12 with equal importance.
NO, it is compulsory to attempt all questions in the JEE Main exam. The JEE Main exam has negative marking and candidates must answer only those questions for which they know the correct answer. Students must note that there are no minimum marks in JEE Main that students need to score. Students gets All India Rank based on the marks they secure in exam and gets admission based on that rank.
JEE Main question paper is in English, Hindi and language selected when you filled application form. In total, JEE Main is in 13 languages and you can select any language out of available options. You cannot switch language of question paper during exam.
Chapterwise weightage of class 11 and 12 topics in JEE Main are mentioned below:
- Physics: Current Electricity Waves AC, Magnetism, Laws of Motion Work, Power and Energy.
- Chemistry the high weightage topics are s and p block elements, Coordination compounds, Thermodynamics Gaseous state, Chemical bonding, Atomic structure, Polymers, Environmental Chemistry Organic Chemistry.
- Mathematics, the high weightage topics are Sequence and Series Vectors and 3D, Integral and Differential Calculus, Definite and Indefinite Integral.
Commonly asked questions
Paper 1 has 75 questions where Physics Chemistry and Mathematics, each section has 25 questions. Out of 25 questions, 20 are MCQs and five are numerical value questions. You must answer all 5 numerical value-type questions. All 20 multiple-choice questions are compulsory. Complete all 75 questions in 3 hours.
There are two question types in JEE Main exam. Multiple choice questions and numerical ability questions. In MCQ, every question has 4 options with only 1 correct answer. Select the correct option. In numerical ability question type, no options are there. Solve them and write answer using keyword and mouse.
Questions in JEE Mains exam is a blend of all the topics covered in the syllabus. However, there are some topics that are very much important and should be paid extra attentions while preparing for the exam. The list of important JEE Main topics are
